104kWh-40kW PV-BESS- EV All-in-one Cabinet
Provide unmatched self sufficiency for your use of energy. Highly integrated modules enable easier installation and maintenance. Comprehensive protection and coordinated control systems meet EV vehicle’s fast-charging safety requirements.
Learn More
Get Free Quote
- Grade-A, latest battery cells
- Build-in EMS, BMS, PCS
- Easy deployment and maintenance
- Meet fast-charging safety requirements
Specifications
104kWh-40kW PV-BESS- EV All-in-one Cabinet
| DC Battery type: LiFePO4 | DC Battery Configuration: 3.2V/314Ah |
| DC Settings: 52S*2S*1P | DC Rated Capacity: 104kWh |
| DC Rated Voltage Range : DC 260-379V | PV-port Max. Power: 38.4kW+38.4kW |
| DC Charge-discharge Rate: 0.5P | AC Rated Power: 40kW |
| System Working Temperature: -20℃~+15℃ | AC Rated Voltage: 400V AC |
| AC Access way: 3P+N+PE | AC Rated grid hertz: 50/ 60Hz |
| PV-port Max. Input Voltage: 850V | PV-port Max. Current: 64A+64A |
| PV-port Start Voltage: 250V | MPPT Voltage Range: 200V~800V |
| System Length×Width×Height: 1780×1350×2300mm | System Weight: 1600±50kg |
| Battery Life Cycles: 8000 | IP54: Liquid cooling |
| Auto Perfluoro (C6F12O) Suppression | Supported Communication Protocols: Ethernet, RS485, CAN |
| System Working Temperature: -20℃~60℃ | Brand: HELZ |
| System Working Altitude: 4000m（declining configuration above 2000m) | MPPT Max. channels: 2 |
